1mx1mx1m Welded Wire Mesh Galvanized Steel Gabion Box Baskets
Gabion Mesh
Product Description ----------------------------------------------------------------------------------------------------------------------------------------------------------
Welded Gabion is made of welded wire mesh panel, it is assembled
with a spiral-shaped wire to assemble the front and rear panels,
the bottom plate and the partition after welding, and is packed
together with the mesh cover. All the caged products that are
folded and tied are an independent individual.Welded Mesh Gabions are constructed using square electro welded
weld mesh panels of high tensile steel. They are increasing in
popularity due to their comparative ease and speed of installation.
They are an economical environmental solution for structural
retaining walls and coastal defences. They are particularly suited
for use in retaining walls due to their permeability and
flexibility. The permeability enables groundwater to flow through
freely when most other retaining wall types will retain ground
water causing hydrostatic pressure to build up behind the wall.
Hydrostatic pressure buildup may result in the wall failing and
collapsing. The flexibility allows gabions to deform a little
without damage when in comparison rigid retaining walls such as
concrete walls would have cracked and crumbled.
Can be Assembled by springs, C-rings. Reinforced by Hooks.
Product Specifications --------------------------------------------------------------------------------------------------------------------------------------------
specification of Gabion Box |
Gabion size(m) | Mesh opening | Wire diameter | Surface treatment |
1×1×1 | 50 x 50mm
75 x 75mm
80 x 80mm
100 x 100mm | 3-6mm | Galvanized
Galfan
PVC coated |
2×1×1 | 3-6mm |
3×1×1 | 3-6mm |
0.5×0.5×0.5 | 3-6mm |
1×0.5×0.5 | 3-6mm |
1×1×0.5 | 3-6mm |
2×1×0.5 | 3-6mm |
Our Gabion box is made from strengthened hot dipped galvanized or
zinc-aluminium coated steel which delivers exceptional corrosion
resistance.
Installation Methods ---------------------------------------------------------------------------------------------------------------------------------------------------
There are two common installation methods for gabion box.
1. Gabion Boxes installation by spring wires.
Welded Gabion Box Accessories |
1 | Welded mesh panel | 6 pcs |
2 | Spiral spindle | 12 pcs |
3 | Corner stiffer | 2-8pcs |
4 | Diaphgram | 1 pc per meter |
2. Gabion Boxes installation by C clips
Using C Clips instead of spring wires is also a common installation
method of gabion boxes. This installation method is simpler and
more economical than spring wires. Ir is also a good choice for
customers.
Gabion Box Advantage ----------------------------------------------------------------------------------------------------------------------------------------------
Technology
Material: low carbon steel wire
Wire diameter:3.0-6.0mm
Surface: passivation and plasticization of electro-galvanized, hot-dip
galvanized, plastic coated, dip-coated or Galvan
Color: silver, green. etc
The wire used to manufacture double twisted gabion wire mesh is
soft annealed, mild steel wire provided with heavy zinc coating as
per EN 10244/ASTM A 641 to prevent corrosion. In case of use in
aggressive environments, it is further extruded with 0.5mm thick
PVC Coating.
Features
Durable structure with greater strength.
Better shape control.
Utmost corrosion resistance.
Easy to assemble.
Aesthetically appearance.Welded Mesh Gabions are constructed using square electro welded
weld mesh panels of high tensile steel. They are increasing in
popularity due to their comparative ease and speed of installation.
They are an economical environmental solution for structural
retaining walls and coastal defences.
Product Applications ------------------------------------------------------------------------------------------------------------------------------------------------------
- Gabion planter.
- Retaining wall.
- Fireplaces.
- Slope protection.
- Landscape construction.
- Road protection.
Company Profile --------------------------------------------------------------------------------------------------------------------------------------------------------------
Anping Bingze Wire Mesh Products Co., Ltd. has focused on the
production and research and development of stainless steel wire
mesh for 25 years. It is a manufacturer integrating production,
processing, distribution and wholesale. The main products include
galvanized welded wire mesh,stainless steel welded wire mesh,PVC
welded wire mesh,crimped wire mesh,galvanized woven wire
mesh,stainless steel woven wire mesh,chain link fence,steel
fence,welded wire mesh fence panels,PVC euro fence,358 anti-climb
fence,razor wire,Hesco Barrier,Gabion Box and so on.Since its
beginning,we have been working at four points, they are High
Quality,Quick Delivery,Better Price and Thorough Service,Rely on
the product quality and our credit standing, we have got favourable
comments from the customers.The company introduces precise making
machines and technics,combinning scientific inner managing method
and quality control system.Since the year it was established ,we
developed our powder and credit standing and got reliances of our
customers in home and abroad.Our products is checking by very high
standeard, and the qualified ones leaved the factory to the whole
county an some aabroad countries,such as Southeast Asia,Middle
East,Ameria,Japan,and some Africa countries.
Certifications --------------------------------------------------------------------------------------------------------------------------------------------------------------------
FAQ ---------------------------------------------------------------------------------------------------------------------------------------------------------------
Q: How long is your delivery time?
Generally it is 3-7 days if the goods are in stock. or it is 15-20
days if the goods are not in stock, it is according to quantity.
Q:Do you provide samples?
Yes, we can provide the product samples for your test.Its free and
freight should be collected by your side.
Q:How can I know the completion of my order?
Deposit payment---start production---transfer infro to
logistic---book shipment--inform customer ETD&ETA---load
container---balance payment---send documents
Q:How can I know whether you are a reliable company?
We have been in this business line since 1987,with too much
exporting experience. Above listed our certifications.
